Sold out
Roll over or click image to zoom in
| Mechanical Parameters | |
|---|---|
| Starting Torque | Max 1gf.cm |
| Usage Temperature | -10℃ ~ +80℃ |
| Max. Speed | 200RPM |
| Shock Resistance | Max 50G |
| Weight | About 413g |
| Service Life | 3 × 105 turn (200r/min Frequency) |
| Protection Rating | IP50 |
| Electrical Parameters | |
|---|---|
| Supply Voltage | DC 5 ±5％ DC12 ±5％ |
| Output Method | Long line drive output Voltage output |
| Response Frequency | 10Khz |
| Working current | ≤30mA |
| Emission Current | ≤40mA |
| ShutDown Current | ≤0.2μA |
| Resolution | 100PPR |
