| Mechanical Parameters | |
|---|---|
| Dimension | 60mm |
| Starting Torque | Max 1gf.cm |
| Material | Aluminum Alloy |
| Weight | About 200g |
| Service Life | 3 × 105 turn (200r/min Frequency) |
| Max. Speed | 200RPM |
| Operating Temperature | -10℃ ~ +80℃ |
| Protection Rating | IP50 |
| Electrical Parameters | |
|---|---|
| Supply Voltage | DC 5 ±5％ DC 24 ±5％ |
| Output Method | Long line drive output Voltage output |
| Maximum Response Frequency | 10Khz |
| Maximum Current Consumption | 80mA Long line drive output 120mA Other |
| Resolution | 25PPR 100PPR |
| Rise/Fall Time | 200ns Differential output 1μs Other output |
