| Mechanical Parameters | |
|---|---|
| Starting Torque | 5x102 |
| Operating Temperature | -20℃ ~ +85℃ |
| Max. Speed | 6000r/min |
| Shock Resistance | 980m/s2（X,Y,Z directions, 2 times each, 6 ms duration each time） |
| Vibration Resistance | 98m/s2（50~2000Hz, X,Y,Z directions, 2h each） |
| Weight | About 318g |
| Protection Rating | IP56 |
| Electrical Parameters | |
|---|---|
| Supply Voltage | DC 5 ±5％ DC 5~24 ±5％ |
| Output Method | Long line drive output Voltage output Open collector Push pull output |
| Maximum Response Frequency | 10Khz |
| Maximum Current Consumption | 80mA Long line drive output 120mA Other |
| Resolution | 100PPR-5000PPR |
| Rise/Fall Time | 200ns Differential output 1μs Other output |
